AFC-2000 Air Filter Pressure Regulator Kit – 1/4″ NPT

The AFC-2000 is a high-quality combination unit consisting of an air filter, pressure regulator, and water separator in one compact housing. It is specifically designed to extend the service life of pneumatic tools, optimize performance, and ensure consistent, clean air supply.

How It Works

As compressed air flows through the unit, it efficiently removes moisture, oil particles, dust, and debris. The built-in pressure regulator maintains a constant working pressure, regardless of fluctuations in the inlet pressure. The transparent polycarbonate bowl allows for quick visual inspection of the condensate level, and water can be drained easily via the manual relief valve.

Technical Specifications

• Model: AFC-2000

• Connection Size: 1/4″ NPT female thread

• Working Pressure: 0.05 – 0.85 MPa (7–125 PSI)

• Maximum Pressure: 1.0 MPa (145 PSI)

• Filtration Accuracy: ~40 microns

• Filter Body Material: Aluminum alloy

• Bowl Material: Impact-resistant polycarbonate

• Operating Temperature: 0–60 °C (32–140 °F)

• Pressure Gauge: Included for precise monitoring

• Mounting: Bracket included

Key Features

• 3-in-1 Function – Combines air filtration, pressure regulation, and water separation in a single unit

• High Filtration Efficiency – Effectively removes water, oil, and dust particles from compressed air

• Consistent Output Pressure – Ensures stable tool performance and reduces wear

• Compact Design – Space-saving, ideal for both stationary and mobile applications

• Durable Construction – Built for continuous industrial use

• Easy Maintenance – Quick condensate drainage without tools

Typical Applications

• Spray Painting – Prevents water and oil marks in paint finishes

• Pneumatic Tools – Increases lifespan and efficiency of impact wrenches, drills, grinders, etc.

• Industrial Machinery – Ensures safe operation of CNC machines and automation systems

• Workshops & Garages – Provides clean, dry compressed air for all types of workshop tasks

Common Applications

• Automotive Workshops – For impact wrenches, air ratchets, tire inflation systems.

• Painting & Finishing – Ensures flawless paint application by removing water/oil.

• Industrial Automation – Keeps air cylinders, valves, and actuators clean and efficient.

• Construction Sites – Reliable air delivery for nailers, staplers, and grinders.

• Home Garages – Perfect upgrade for hobbyists and DIY compressed air systems.

Why It’s Essential

Compressed air often contains moisture, oil mist, and solid particles that can cause corrosion, blockages, and reduced efficiency. The AFC-2000 addresses these problems with:

1. Effective Filtration – Captures dust, rust, and debris down to ~40 microns.

2. Moisture Removal – Traps condensed water before it reaches your tools.

3. Precise Pressure Control – Maintains a steady operating pressure for consistent tool performance.
