IFM IF5313 Inductive Proximity Sensor IF‑3002‑BPKG/55V

IFM IF5313 Inductive Proximity Sensor IF‑3002‑BPKG/55V

Model: IF-3002-BPKG/55V
Type: Flush-mounted inductive proximity sensor with PNP output
Thread / Length: M12 × 1, length 71 mm
Output: PNP, Normally Open (NO)
Connection: 2 m PVC cable, 3-wire

⚙️ Detection Characteristics

• Nominal Sensing Distance (Sn): 2 mm ±10%

• Usable Sensing Range (Sr): 0–1.6 mm

• Hysteresis: 1–15% of Sn (typical)

• Switching Frequency: Up to 800 Hz

• Switching Status Indicator: Yellow LED

• Target Material: Ferromagnetic metal (mild steel = 1.0 correction factor)

• Correction Factors (approx.):

  • Stainless Steel: 0.7

  • Brass: 0.4

  • Aluminum: 0.3

  • Copper: 0.2

⚡ Electrical Data

• Supply Voltage (UB): 10–55 V DC

• Current Consumption (no load): < 15 mA

• Output Type: PNP, Normally Open

• Max Load Current: 250 mA

• Voltage Drop (ON): < 2.5 V

• Protection Circuits:

  • Reverse Polarity Protection

  • Short-Circuit Protection (pulsed)

  • Overload Protection

• Output Type Compliance: IEC 60947-5-2

🌡 Environmental & Mechanical Specifications

• Operating Temperature Range: –25 °C to +80 °C

• Storage Temperature Range: –40 °C to +85 °C

• Protection Rating: IP67

• Housing Material: PBT (polybutylene terephthalate)

• Sensing Face Material: PBT

• Thread Size: M12 × 1

• Total Length: 71 mm

• Cable Type: 2 m, PVC, 3 × 0.34 mm²

• Weight: Approximately 88.5 g

• Mounting Hardware: 2 lock nuts included

📋 Standards & Reliability

• Protection Class: II

• Electromagnetic Compatibility: EN 60947-5-2 compliant

• Mean Time to Failure (MTTF): ~945 years

• Shock and Vibration Resistance: Suitable for industrial automation and machinery environments
